1) The attached pictures show main frame of standard RH1000 Strip Edge Rounding and Deburring machine. It is the smallest standard model of RH series product. In practical application, we have also delivered RH800 Strip Edge Trimming machine for customer;
2) Compared with RH1500 and larger models of Plate Edge Rounding machine, RH1000 and smaller RH800 have open structure, instead of enclosed frame mechanical body. The reason behind that is explained below.
1) This model of the Strip End Plate Trimming machine is for edge rounding and deburring workpiece up to 1000mm width. Due to its relative narrow size, there is no hidden risk of center drum up on the workpiece in the process of edge rounding;
2) Consequently, it is not necessary to have the downward stroke pressing rollers, which are equipped in the larger models of RH1500, RH2000, and RH3000 higher power Edge Rounding and Deburring machine. Check below: (Fig.1)
a) RH1000 Strip Edge Rounding machine has the frame with top open structure, that a set of base bed is installed with rounding unit on it;
b) Together with input and output conveyors deployed at its front and rear side, to form up complete system of this RH1000 Strip Edge Rounding and Deburring machine;
Another discrepancy, or uniqueness of RH1000 Strip Edge Rounding machine, from the larger ones of RH1500, RH2000, and RH3000 lies at its moving way, or alignment of rounding units at both sides:
1) Please check attached picture and below photo. One side of the up and down rounding rollers are fixed along horizontal direction: (Fig.2)
2) While the opposing side of rounding rollers are transverse movable guided with the guiding rod and bush;
3) For RH series Edge Rounding machine, these guiding rod and bush are made of finely machined 45# steel with Chrome plating: (Fig.3)
4) The distance between the two pairs of rounding rollers is adjusted with the moving side of the rounding rollers, accommodating workpiece of various width within the range of 1000 mm;
5) Comparatively, in the case of larger models of RH1500, RH2000, and RH3000 Plate Edge Rounding and Deburring machine, both sides of the rounding rollers can be moved along transverse direction;
6) The 3rd disparity of RH1000 and smaller models of automatic Strip Edge Trimming machine is its foundation: No need to prepare it ahead of time before installation. Just secure its machine body and conveyors into workshop ground with the anchor bolts.
Below are technical specifications of this RH1000 High Precision Strip End Plate Trimming Machine:
RH1000 Strip Edge Rounding and Deburring Machine | ||
No. | Item | Parameter |
1 | Workpiece Width | 150 ~ 1000 mm |
2 | Workpiece Thickness | 10 ~ 40 mm |
3 | Workpiece Length | 1000 ~ 12000 mm |
4 | Suit H Beam Min Web Beam Height | 320 mm |
5 | Rounding Speed | 7200 mm/min. |
6 | Rounding Radius | R2.5 mm |
7 | Main Rollers Diameter | φ300 mm |
8 | Hydraulic Station | 4 kW |
9 | Max. Pressure in Hydraulic System | 12 MPa |
10 | Input and Output Conveyor Length | 10m each |
11 | Machine Total Power | 10.6 kW |
12 | Power | 380V, 50Hz, 3P |
1) The attached pictures show main frame of standard RH1000 Strip Edge Rounding and Deburring machine. It is the smallest standard model of RH series product. In practical application, we have also delivered RH800 Strip Edge Trimming machine for customer;
2) Compared with RH1500 and larger models of Plate Edge Rounding machine, RH1000 and smaller RH800 have open structure, instead of enclosed frame mechanical body. The reason behind that is explained below.
1) This model of the Strip End Plate Trimming machine is for edge rounding and deburring workpiece up to 1000mm width. Due to its relative narrow size, there is no hidden risk of center drum up on the workpiece in the process of edge rounding;
2) Consequently, it is not necessary to have the downward stroke pressing rollers, which are equipped in the larger models of RH1500, RH2000, and RH3000 higher power Edge Rounding and Deburring machine. Check below: (Fig.1)
a) RH1000 Strip Edge Rounding machine has the frame with top open structure, that a set of base bed is installed with rounding unit on it;
b) Together with input and output conveyors deployed at its front and rear side, to form up complete system of this RH1000 Strip Edge Rounding and Deburring machine;
Another discrepancy, or uniqueness of RH1000 Strip Edge Rounding machine, from the larger ones of RH1500, RH2000, and RH3000 lies at its moving way, or alignment of rounding units at both sides:
1) Please check attached picture and below photo. One side of the up and down rounding rollers are fixed along horizontal direction: (Fig.2)
2) While the opposing side of rounding rollers are transverse movable guided with the guiding rod and bush;
3) For RH series Edge Rounding machine, these guiding rod and bush are made of finely machined 45# steel with Chrome plating: (Fig.3)
4) The distance between the two pairs of rounding rollers is adjusted with the moving side of the rounding rollers, accommodating workpiece of various width within the range of 1000 mm;
5) Comparatively, in the case of larger models of RH1500, RH2000, and RH3000 Plate Edge Rounding and Deburring machine, both sides of the rounding rollers can be moved along transverse direction;
6) The 3rd disparity of RH1000 and smaller models of automatic Strip Edge Trimming machine is its foundation: No need to prepare it ahead of time before installation. Just secure its machine body and conveyors into workshop ground with the anchor bolts.
Below are technical specifications of this RH1000 High Precision Strip End Plate Trimming Machine:
RH1000 Strip Edge Rounding and Deburring Machine | ||
No. | Item | Parameter |
1 | Workpiece Width | 150 ~ 1000 mm |
2 | Workpiece Thickness | 10 ~ 40 mm |
3 | Workpiece Length | 1000 ~ 12000 mm |
4 | Suit H Beam Min Web Beam Height | 320 mm |
5 | Rounding Speed | 7200 mm/min. |
6 | Rounding Radius | R2.5 mm |
7 | Main Rollers Diameter | φ300 mm |
8 | Hydraulic Station | 4 kW |
9 | Max. Pressure in Hydraulic System | 12 MPa |
10 | Input and Output Conveyor Length | 10m each |
11 | Machine Total Power | 10.6 kW |
12 | Power | 380V, 50Hz, 3P |
